Inversores de 110 VMUST
PV1900 TLV
Inversor solar MUST PV1900 TLV da linha 2026, com potência de 8–12 kW e saída CA de 120/240 V. Consulte a ficha completa para comparar modelos, proteções, comunicação, dados elétricos e dimensões.
Potência8–12 kW
Saída CA120/240 V
Bateria48 V
TopologiaSplit phase
Principais parâmetros da série
| PARÂMETROS PRINCIPAIS | |||
|---|---|---|---|
| MODELO | PV19-8K-TLV | PV19-10K-TLV | PV19-12K-TLV |
| Rated power | 8000W | 10000W | 12000W |
| DADOS DE ENTRADA DA BATERIA | |||
| Battery type | Lead-acid battery / Lithium battery | ||
| Battery voltage | 48V | ||
| Charging Strategy for Li-lon Battery | Self-adaption to BMS | ||
| Maximum charging/discharging power | 8000W | 10000W | 12000W |
| Maximum charging/discharging current | 180A | 200A | 220A |
| DADOS DA ENTRADA FV | |||
| Max. DC Input Power | 12000W | ||
| Maximum DC Input Power of each | 6000W | ||
| Maximum DC voltage | 550V | ||
| Start-up Voltage | 100V | ||
| Rated PV Input Voltage | 370V | ||
| PV Maximum Input Current | 26A+26A | ||
| PV Maximum Short Circuit Current | 44A+44A | ||
| MPPT quantity | 2 | ||
| Number Of MPPT Strings Per Channel | 1+1 | ||
| AC INPUT/OUTPUT DATA | |||
| Rated AC Input/output active power | 8000W | 10000W | 12000W |
| Max. AC Input/output apparent power | 8000W | 10000W | 12000W |
| Rated AC Input/output current | 33.4A | 41.7A | 50A |
| Max. AC Input/output current | 33.4A | 41.7A | 50A |
| Max. Continuou AC passthrough (grid to load) | 60A | 60A | 60A |
| Rated Input/output voltage/ range | 120V/240V:208V | ||
| Rated Input/output grid frequeney/ range | 60Hz±5Hz/ 50Hz±5Hz | ||
| Rated output power factor | 1 | ||
| Power factor adjustment range | 0.8 leading to 0.8 lagging | ||
| Total Hamonics CurentDistortion (THDi) | <3% | ||
| Grid Type | Split Phase | ||
| DC Current Injection | <0.5% | ||
| OUTROS PARÂMETROS | |||
|---|---|---|---|
| MODELO | PV19-8K-TLV | PV19-10K-TLV | PV19-12K-TLV |
| PROTECTION | |||
| Integrated | Islanding protection, Output overcurrent protection, Output overvoltage protection,PV input polarity reverse protection, Battery Over-current protection/ Battery Over-temperature protection | ||
| GENERAL DATA | |||
| Operating Temperature Range (°C) | -10°C~+60°C | ||
| Cooling | Intelligence Fan | ||
| Noise (dB) | ≤55dB | ||
| Altitude | 3000m, >3000mDerating | ||
| Communication | USB/ WiFi/ Enternet (optional) | ||
| Display | 4.3-inch touch screen | ||
| Protection Degree | IP21 | ||
| Installation Style | Wall-mounted | ||
| ESPECIFICAÇÕES MECÂNICAS | |||
| Machine Dimension (W*H*D)(mm) | 487*693*142 | ||
| Package Dimension (W*H*D)(mm) | 744*257*612 | ||
| N.W(kg) | 28 | ||
| G.W(kg) | 30 | ||
| Warranty | 2 year | ||
| CERTIFICAÇÕES E NORMAS | |||
| Rohs; CE-EMC; CE-LVD (62109-1/-2); INMETRO(Brazil); NBT32004-2013; UL1741; FCC | |||
O preço depende do modelo e da configuração.
