Bateria LiFePO4 MUST LP2100 do catálogo 2026
MUST EnergySolução durável
Baterias LiFePO4MUST

LP2100

Bateria LiFePO₄ MUST LP2100 da linha 2026, com energia de 14,3–16,3 kWh e tensão nominal de 51,2 V. Consulte a ficha completa para comparar modelos, proteções, comunicação, dados elétricos e dimensões.

Energia14,3–16,3 kWh
Tensão nominal51,2 V
Capacidade280–320 Ah
ComunicaçãoWi-Fi
Solicitar orçamento Ficha técnica PDF

Principais parâmetros da série

PARÂMETROS PRINCIPAIS
Dados técnicosLP21-48280LP21-48300LP21-48320
Nominal Voltage51.2V
Nominal Capacity280Ah300Ah320Ah
Nominal energy14336Wh15360Wh16384Wh
Max. output power10KW 10KW 10KW
Life Cycles≥6000(25°C+2°C)
Recommended Charge Voltage57.6V
Recommended Charge Current56A60A60A
End Of Discharge Voltage44V
Standard Charge Current56A60A60A
Standard Discharge Current140A150A150A
Maximum Continuous Charge Current200A200A150A
Maximum Continuous Discharge Currentt200A200A150A
BMS Cut-Off Voltage Charge58.4 V (3.65V/Cell)
BMS Cut-Off Voltage Discharge44.0V (2.75V/Cell)
Temperature Charge0~50°C
Temperature Discharge-20~55°C
Storage Temperature-5~35°C
Shipment voltage≥51.2V
Module ParallelUp to 15 units
OUTROS PARÂMETROS
Dados técnicosLP21-48280LP21-48300LP21-48320
CommunicationCAN2.0/RS232/RS485
Case MaterialSPCC
Machine Dimension (W*H*D) (mm)260*733*633
Package Dimension
(W*H*D) (mm)		wooden box440*870*720
N.W (kg)118
G.W (kg)wooden box138
* Variations in dimensions and weights may occur due to production batches.
Charge Retention And
Capacity Recovery Capability		Standard charge the battery, and then put aside at room temperature for 28d or 55°C for 7d, Charge
retention rate≥90%, Recovery rate of charge≥90%
Warranty5 years
Certification & StandardsCE-EMC(EN 61000-6-3: 2007+A1: 2011+AC: 2012 EN IEC 61000-6-1: 2019)
UN38.3/ MSDS / IEC62619:2017

O preço depende do modelo e da configuração.
